In the design and manufacture of disposable non-bladed puncture needles, the selection of materials is not arbitrary. It is a scientific decision made based on strict clinical requirements, biocompatibility regulations, and physical performance standards. Different material combinations directly define the performance boundaries, application scenarios, and market positioning of the product.

1. Metal Components: Balancing Strength, Corrosion Resistance, and Biocompatibility

The cannula is the main structural component of the puncture needle. The selection of its material primarily takes into account strength, rigidity, corrosion resistance, and biocompatibility.

• 304 and 316L austenitic stainless steel: These are the most common choices. 304 stainless steel has excellent comprehensive mechanical properties and corrosion resistance and offers good cost performance. While 316L stainless steel, due to the addition of molybdenum, has stronger resistance to chloride ion pitting and better biocompatibility, it is the preferred choice for higher-grade surgical instruments, especially suitable for scenarios involving long surgeries or where there are strict requirements for the release of metal ions from implanted materials.
• L605 cobalt-chromium alloy: This is a high-end material with higher hardness (HRC 20-40), wear resistance, and fatigue resistance compared to stainless steel. When extreme thin-wall design is required to maximize the inner diameter (for example, a 5mm cannula needs to accommodate a 5mm instrument), and high structural strength is demanded, L605 becomes an ideal choice. However, its processing difficulty and cost also increase significantly.
• Nickel-titanium alloy: Known for its unique superelasticity and shape memory effect. Although not commonly used in conventional puncture needle cannulas, it shows potential in the development of flexible or intelligent puncture devices, capable of adapting to non-linear puncture paths.

2. Plastic Part: Transparency, Toughness, and Sealing Function

Plastic components perform functions such as piercing, sealing, and operational interfaces, and their selection criteria are quite different from those of metals.

• Polycarbonate: It is the preferred material for manufacturing transparent puncture tips. Its extremely high optical transparency, excellent impact strength, and dimensional stability enable doctors to clearly identify tissue layers during puncture, and the cone head is less likely to rupture when penetrating the tissue. Common models such as Makrolon 2458 were developed specifically to meet the requirements of medical devices for high transparency, chemical resistance, and gamma radiation sterilization.
• ABS resin: It is commonly used for handles and valve body casings. It has good comprehensive mechanical properties, easy processability, and surface finish, providing a comfortable operating feel and reliable shell protection.
• Medical silicone: It is the core material for seals (such as trumpet valves, gaskets). Silicone has excellent elasticity, flexibility, and biocompatibility, can be repeatedly passed through by the equipment and quickly restore sealing, ensuring the stability of pneumoperitoneum, and has little friction with the equipment surface, ensuring smooth operation.
• Nylon: It is often used to manufacture threaded connection components or certain structural parts. It has good wear resistance and high strength and can withstand repeated screwing operations.

3. Mapping of Material Combinations to Clinical Requirements

The selection of materials ultimately serves the clinical needs. For example:

A complex laparoscopic liver surgery may require more corrosion-resistant 316L stainless steel cannulas and fine dissecting forceps made of L605 alloy, along with ultra-transparent polycarbonate tips to ensure safety and clear vision during long surgeries.

For conventional gynecological or gallbladder surgeries, the 304 stainless steel combined with high-performance plastic solution can fully meet the requirements, demonstrating the best cost-effectiveness.

For "scarless surgeries" such as natural orifice transluminal endoscopic surgery (NOTES) or single-port laparoscopic surgery (LESS), smaller diameter and higher strength L605 cannulas, as well as materials with special flexibility or shape memory properties, may be needed to cope with more narrow and more tortuous operating spaces.

Conclusion

Therefore, the material list of the one-time non-bladed puncture needle actually serves as a microcosm of clinical engineering. From the "rigidity" of stainless steel to the "softness" of silicone, from the "transparency" of polycarbonate to various alloys with their "stiffness," each material plays an irreplaceable role in the microscopic world of the puncture needle due to its unique performance characteristics. The manufacturers' profound understanding and precise application of the materials are the fundamental for creating differentiated and high-quality products.
